We know that the three major concerns of purchasers of bearing products are: first, the delivery time is not on schedule, the quality of the samples and the actual delivered goods is inconsistent, and the after-sales service cannot find the responsible person in time. Therefore, before each batch of goods leaves the factory, we take videos and send them to the customers for confirmation. We promise to respond to after-sales issues within 24 hours. We have assigned a dedicated follow-up person for each customer to better and faster solve after-sales problems. Last year, we delivered 5 million pieces for customers from many countries, with an excellence rate of 99.2%. We have passed ISO and CCIC certifications, and the reports can be queried. We have more than 30 international customers who have cooperated with us for over 5 years, perfectly meeting their demands and solving their concerns.
| No. | Bearing type | Dimension | Rated dynamic load Cr(Kn) | Raled static load Cor(Kn) | Weight(Kg) | |||||||
| Current code | Original code | d | D | B | C | T | Rmin | rmin | ||||
| 1 | 30205 | 7205E | 25 | 52 | 15 | 13 | 16.25 | 1 | 1 | 32.2 | 37 | 0.153 |
| 2 | 30206 | 7206E | 30 | 62 | 16 | 14 | 17.25 | 1 | 1 | 43.3 | 50.5 | 0.231 |
| 3 | 30207 | 7207E | 35 | 72 | 17 | 15 | 18.25 | 1.5 | 1.5 | 54.4 | 63.5 | 0.332 |
| 4 | 30208 | 7208E | 40 | 80 | 18 | 16 | 19.75 | 1.5 | 1.5 | 63 | 74 | 0.417 |
| 5 | 30209 | 7209E | 45 | 85 | 19 | 16 | 20.75 | 1.5 | 1.5 | 67.9 | 83.6 | 0.473 |
| 6 | 30210 | 7210E | 50 | 90 | 20 | 17 | 21.75 | 1.5 | 1.5 | 73.3 | 92.1 | 0.529 |
| 7 | 30211 | 7211E | 55 | 10 | 21 | 18 | 22.75 | 2 | 1.5 | 90.8 | 113.7 | 0.715 |
| 8 | 30212 | 7212E | 60 | 110 | 22 | 19 | 23.75 | 2 | 1.5 | 103.3 | 130 | 0.905 |
| 9 | 30213 | 7213E | 65 | 120 | 23 | 20 | 24.75 | 2 | 1.5 | 120.6 | 152.6 | 1.13 |
| 10 | 30215 | 7215E | 75 | 130 | 25 | 22 | 27.25 | 2 | 1.5 | 138.4 | 185.4 | 1.36 |
| 11 | 30216 | 7216E | 80 | 140 | 26 | 22 | 28.25 | 2.5 | 2 | 160.4 | 212.8 | 1.68 |
| 12 | 30217 | 7217E | 85 | 150 | 28 | 24 | 30.5 | 2.5 | 2 | 177.6 | 236.8 | 2.06 |
| 13 | 30219 | 7219E | 95 | 170 | 32 | 27 | 34.5 | 3 | 2.5 | 226.6 | 309 | 3.06 |
| 14 | 30220 | 7220E | 100 | 180 | 34 | 29 | 37 | 3 | 2.5 | 253.9 | 350.3 | 3.74 |
| 15 | 30305 | 7305E | 25 | 62 | 17 | 15 | 18.25 | 1.5 | 1.5 | 46.9 | 48.1 | 0.266 |
| 16 | 30306 | 7306E | 30 | 72 | 19 | 16 | 20.75 | 1.5 | 1.5 | 59 | 63.1 | 0.385 |
| 17 | 30307 | 7307E | 35 | 80 | 21 | 18 | 22.75 | 2 | 1.5 | 75.3 | 82.6 | 0.515 |
| 18 | 30308 | 7308E | 40 | 90 | 23 | 20 | 25.25 | 2 | 1.5 | 90.9 | 107.6 | 0.748 |
| 19 | 30309 | 7309E | 45 | 100 | 25 | 22 | 27.25 | 2 | 1.5 | 108.9 | 129.8 | 0.987 |
| 20 | 30310 | 7310E | 50 | 110 | 27 | 23 | 29.25 | 2.5 | 2 | 130.1 | 157.1 | 1.289 |
| 21 | 30311 | 7311E | 55 | 120 | 29 | 25 | 31.5 | 2.5 | 2 | 153.3 | 187.6 | 1.635 |
| 22 | 30312 | 7312E | 60 | 130 | 31 | 26 | 33.5 | 3 | 2.5 | 192.7 | 209.9 | 2.003 |
| 23 | 30313 | 7313E | 65 | 140 | 33 | 28 | 36 | 3 | 2.5 | 195.9 | 241.7 | 2.44 |
| 24 | 30314 | 7314E | 70 | 150 | 35 | 30 | 38 | 3 | 2.5 | 219 | 271.7 | 2.98 |
| 25 | 30315 | 7315E | 75 | 160 | 37 | 31 | 40 | 3 | 2.5 | 252.8 | 318.8 | 3.586 |
| 26 | 30316 | 7316E | 75 | 160 | 37 | 31 | 40 | 3 | 2.5 | 252.8 | 318.8 | 3.586 |
| 27 | 30317 | 7317E | 85 | 180 | 41 | 34 | 44.5 | 4 | 3 | 304.9 | 388.2 | 4.96 |
| 28 | 30318 | 7318E | 90 | 190 | 43 | 36 | 46.5 | 4 | 3 | 342 | 440 | 5.8 |
| 29 | 32207 | 7507E | 90 | 190 | 43 | 36 | 46.5 | 4 | 3 | 342 | 440 | 5.8 |
| 30 | 32208 | 7508E | 40 | 80 | 23 | 19 | 24.75 | 1.5 | 1.5 | 77.9 | 97.2 | 0.531 |
| 31 | 32209 | 7509E | 45 | 85 | 23 | 19 | 24.75 | 1.5 | 1.5 | 80.7 | 104 | 0.573 |
| 32 | 32210 | 7510E | 50 | 90 | 23 | 19 | 24.75 | 1.5 | 1.5 | 82.8 | 107.6 | 0.626 |
| 33 | 32211 | 7511E | 55 | 100 | 25 | 21 | 26.75 | 2 | 1.5 | 108 | 142.3 | 0.853 |
| 34 | 32212 | 7512E | 60 | 110 | 28 | 24 | 29.75 | 2 | 1.5 | 132.8 | 179.6 | 1.168 |
| 35 | 32213 | 7513E | 65 | 120 | 31 | 27 | 32.75 | 2 | 1.5 | 160.9 | 221.7 | 1.544 |
| 36 | 32214 | 7514E | 70 | 125 | 31 | 27 | 33.25 | 2 | 1.5 | 168.5 | 237.1 | 1.643 |
| 37 | 32215 | 7515E | 75 | 130 | 31 | 27 | 33.25 | 2 | 1.5 | 170.3 | 242.1 | 1.75 |
| 38 | 32216 | 7516E | 80 | 140 | 33 | 28 | 35.25 | 2.5 | 2 | 198.1 | 279 | 2.132 |
| 39 | 32217 | 7517E | 85 | 150 | 36 | 30 | 38.5 | 2.5 | 2 | 226.7 | 324 | 2.68 |
| 40 | 32218 | 7518E | 90 | 160 | 40 | 34 | 42.5 | 2.5 | 2 | 269.8 | 395.5 | 3.47 |
| 41 | 32219 | 7519E | 95 | 170 | 43 | 37 | 45.5 | 3 | 2.5 | 302.5 | 448.4 | 4.24 |
| 42 | 32220 | 7520E | 100 | 180 | 46 | 39 | 49 | 3 | 2.5 | 341 | 512 | 5.1 |
| Bearing Unit No. | Dimensions(mm) | Shaft shoulder dimensions(mm) | |||||||||||
| d | D | T | C | a | da | db | Da | Db | Ca | Cb | ra | rb | |
| 580/572 | 82.55 | 139.992 | 36.512 | 28.575 | 30.922 | max.94 | min.96.5 | min.120 | min.131 | min.5 | min.7.5 | max.3.5 | max.3.3 |
| SET401 | |||||||||||||
| 594A/592A | 95.25 | 152.4 | 39.688 | 30.162 | 36.588 | max.104 | min.112.5 | min.128 | min.141 | min.4 | min.9.5 | max.5 | max.3.3 |
| SET403 | |||||||||||||
| 3782/3720 | 44.45 | 93.264 | 30.163 | 23.812 | 21.71 | max.60 | min.57.5 | min.80 | min.87 | min.4 | min.6 | max.3.5 | max.3.3 |
| SET406 | |||||||||||||
| 807040/807010 | 2 in | 4.125 in | 1.437 in | 40466 lbf | |||||||||
| SET84 | |||||||||||||
| HM212049/HM212011 | 2.625 in | 4.813 in | 1.51 in | 42039 lbf | |||||||||
| SET413 | |||||||||||||
Factory introduction and inspection guarantee
Exhibition style
Certifications and qualifications
FAQ
A :We regularly attend global exhibitions and look for long-term partners
A :We are a pillow block bearing factory in Liaocheng, Shandong, China. We have our own warehousing and processing production lines and are a local famous factory
A : We uphold honest cooperation, support any form of inspection, and look forward to establishing a long-term and stable cooperative relationship.
A:We will provide standard samples within the contract and deliver the products in full accordance with the quality of the samples. Our service tenet is to satisfy our partners.
A : We have multiple warehouses with stock of UCF series,UCP series,UCFL series,UCT series and other models, and reserve more regular sizes, as well as hot-selling products.
A:Regular sizes can be shipped within 3 days after receiving payment. Some products may need to be customized, but we will try to shorten the delivery time and provide the best service to our partners.
A : We have a complete industrial chain from raw material processing to finished product manufacturing, Product types are: UCF series,UCP series,UCFL series,UCT series and other models, Material: Daye steel, metallographic structures meet international standards。we use thicker inner and outer rings,but don't increase price ! runout value control in the micron level, C3 gap range.The seal between the bearing housing and the bearing is very high, and the lubricating oil can enter the bearing from the inside of the bearing to play a lubricating role in increasing the service life of the bearing. 100% Anderon meter test, eliminate any product with noise.The bearing housing has been upgraded to ensure that the contact surface and force point between the bearing housing and the equipment are increased to ensure the stability of the bearing housing.
Next, we will establish warehouses in countries with more partners so that we can better serve our long-term partners.
A :You need to provide the following information so that I can give you the most advantageous ex-factory price.
Please provide the product name, model, target price, application,, final purchase quantity and the estimated time of receiving the goods in your country/region that you need.
